Deye SUN-5K-SG04LP3-EU 5kW Three-Phase Low Voltage Hybrid Solar Inverter

€1,843.88 tax excluded
€2,267.97 tax included

VAT: 23%
or 0% for companies in the EU

Warehouse Wałbrzych
Delivery to
Poland
Austria
Belgium
Bulgaria
Croatia
Cyprus
Czechia
Denmark
Estonia
Finland
France
Germany
Greece
Hungary
Ireland
Italy
Latvia
Lithuania
Luxembourg
Malta
Netherlands
Poland
Portugal
Romania
Slovakia
Slovenia
Spain
Sweden

Shipping cost

€11.21/package

€54.77/palette

1 Item

Files: 28951
Description
Deye
28951

Data sheet

Warranty5
Power [kW]5.0
Weight (kg)33.6
Number of phases3-fazowy
Number of MPPTs2

The Deye SUN-5K-SG04LP3-EU is a 5kW three-phase low voltage hybrid solar inverter engineered for residential and light commercial applications. Distributed by V-TAC, this inverter enables significant energy independence and optimized energy flow, allowing users to harness solar power efficiently.

  • Rated AC Output: 5000W (5kW), with a max output of 5500W
  • Three-Phase Power: Designed for three-phase electrical systems, ensuring stable and efficient power distribution.
  • Low Voltage Battery: Compatible with 40-60V batteries (48V nominal), supporting both lead-acid and lithium-ion options.
  • Dual MPPT Trackers: Features 2 MPPT trackers to maximize energy harvest from solar panels.
  • Wide MPPT Voltage Range: Operates within a 200-650V MPPT voltage range, offering flexibility in panel configuration.
  • High Efficiency: Boasts a max efficiency of 97.6% and European efficiency of 97%.
  • IP65 Protection: Offers robust protection against dust and moisture, making it suitable for various environmental conditions.
  • Hybrid Functionality: Supports on-grid, off-grid, and UPS modes for versatile operation.
  • Unbalanced Output: Capable of 100% unbalanced output, with each phase delivering up to 50% of the rated power.
  • Parallel Operation: Allows parallel connection of up to 10 units for increased power output.
  • Smart Monitoring: Provides remote monitoring and management via Wi-Fi/RS485/CAN.
  • Generator Compatibility: Supports energy storage from a diesel generator.
  • Safety Features: Includes comprehensive protections against overload, over temperature, short circuits, and more.

The Deye SUN-5K-SG04LP3-EU hybrid inverter stands out with its robust design and advanced features. It seamlessly integrates into both existing and new solar power systems, offering users enhanced control over their energy consumption. With its user-friendly interface, comprehensive monitoring capabilities, and exceptional safety features, this inverter is a reliable choice for those seeking energy independence and optimized energy solutions.
