JA Solar JAM66D46-710/LB N-Type Double Glass Bifacial

The JA Solar JAM66D46-710/LB is a state-of-the-art N-Type Double Glass Bifacial module designed for superior performance and durability. Engineered with Deep Blue 4.0 Pro technology, this module delivers exceptional power output and long-term reliability, making it an ideal choice for a wide range of solar energy projects.

• High Power Output: Delivers up to 710W of power, maximizing energy generation.
• N-Type TOPCon Technology: Offers high efficiency and minimal degradation over time.
• Bifacial Design: Captures sunlight from both sides of the module, increasing energy yield with a bifaciality of 80% ± 10%.
• Double Glass Construction: Provides enhanced durability and protection against environmental factors.
• MBB Half-Cell Technology: Improves current collection and reduces power loss, enhancing overall performance.
• Excellent Low-Irradiance Performance: Ensures consistent energy production even in low-light conditions.
• Low Temperature Coefficient: Maintains stable performance in high-temperature environments.
• Dimensions: 2384 mm x 1303 mm x 33 mm.
• Efficiency: Boasts a module efficiency of 22.9%.
• Robust Build: Features a silver anodized aluminum frame and 2.0 mm tempered glass for both front and back.
• Safety: Equipped with an IP68 rated junction box and 3 bypass diodes for enhanced safety and reliability.
• Warranty: Comes with a 12-year product warranty and a 30-year linear power output warranty.

The JA Solar JAM66D46-710/LB module is built with monocrystalline n-type TOPCon cells and advanced technologies to ensure high efficiency and long-lasting performance. Its bifacial design and double glass construction make it a reliable and efficient choice for any solar installation. This module's certifications, including IEC and UL standards, guarantee its quality and safety, making it a trusted component for your solar energy system.
