KEHUA BCS 3000K-B-HUD/T Containerized Energy Storage & Transformer Turnkey System 1500Vdc

The KEHUA BCS 3000K-B-HUD/T 1500Vdc Containerized Energy Storage & Transformer Turnkey System represents a cutting-edge solution for energy storage needs. This system is engineered for high performance and reliability, making it an ideal choice for various applications requiring efficient energy management.

• Rated AC Output Power: 3000kW
• Max. DC Voltage: 1500V
• High PCS Efficiency: Up to 99.03%
• Integrated Design: Combines converter and step-up functionalities for integrated delivery
• Operating Temperature: Adaptable to extreme environments including high temperature, salt, and extreme cold.
• Advanced Topology: Utilizes advanced ANPC three-level topology
• Unified Interface: External communication interface supporting IEC61850
• Multi-Function Support: Supports multi-machine parallel connection, VSG, PQ, VF, and cold start functions
• Grid Adaptability: H/LVRT (High/Low Voltage Ride Through) function ensures high adaptation ability to the grid
• Comprehensive Monitoring: Real-time transformer condition monitoring and cell status fully monitoring
• Enhanced Protection: Multi-level fire protection and on-line insulation detection
• Overload Capacity: 1.1 times long-term overload, 45ºC full load operation

This turnkey system is designed for optimal space utilization and ease of deployment, featuring a highly integrated and efficient layout. With its robust design and intelligent features, the KEHUA BCS 3000K-B-HUD/T is suitable for peak shaving, frequency modulation, and auxiliary grid connection for new energy systems. Experience reliable and efficient energy storage with this state-of-the-art containerized system.
